用於PET瓶的三合一機器將沖洗，灌裝和封蓋的功能集成在一起。基於國外先進技術，並根據注水加工要求設計
主要特點
1. This machine has a compact structure, completed control system, easy to operate and highly automated.
2. By changing the star-wheel, screw bottle inlet and arc guide plate can realize to change the bottle shape.
3. The parts that direct contact with product are made of food grade stainless steel and no technology corner pockets and easy to clean.
4. By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.
5. The machine adopts high effective cap sorting system and completely self control and protective device.
6. The machine is equipped with perfect overload protective device that can keep the equipment and operator safely.
7. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
8. The electric components and pneumatic components are all introduced from world famous brand products.
| 工作崗位數量 | 沖洗32，填充32，加蓋10 |
| 生產能力 | 15000BPH（500ml）中 |
| 氣源壓力 | 0.7兆帕 |
| 耗氣量 | 1.2立方米/分鐘 |
| 沖洗水壓 | 0.2-0.25Mpa |
| 沖洗水容量 | 2.5T / H |
| 主電機功率 | 3.2KW |
| 總功率 | 4.8千瓦 |
| 尺寸 | 4250X2150X2200mm（長×寬×高） |
| 重量 | 5200公斤 |
我們還提供全自動純淨水灌裝廠
它包括4個主要部分：
1. Plastic bottle blow molding machine
2. Water cleaning system
3. Water washing, filling, capping machine.
4. Conveyor system, labeling machine, dating machine, film wrapping machine
完整的行主要描述：
1. The plant can produce different volume bottles, from 200ml to 2000ml bottles, round and square bottles, plastic and glass bottles. It is very easy to change the different bottle molds.
2. The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.
3. We have different speed plants, commonly, 2000BPH, 4000BPH, 7000BPH, 10,000BPH, 15000BPH..ect.
4. The material is stainless steel 304, food grade much clean and safe.
5. We provide the engineers for customer installation, training in customer's factory.
型號和速度列表
| 模型 | XGF8-8-3 | XGF14 / 12/5 | XGF16 / 16/5 | XGF24 / 24/8 | XGF32 /一十分之三十二 |
| 洗手 | 8 | 14 | 16 | 24 | 32 |
| 灌裝閥門 | 8 | 12 | 16 | 24 | 32 |
| 封頂的手 | 3 | 5 | 5 | 8 | 10 |
| 合適的PET /玻璃瓶（150ml至2000ml） | |||||
| 能力（速度） 基於500毫升 | 2000BPH | 5000BPH | 7000BPH | 12000BPH | 15000BPH |
電氣元件品牌供應商
| 主要成分 | 描述供應商 |
| PLC | 三菱（日本），西門子（德國） |
| 觸摸屏 | 威綸（台灣） |
| 頻率轉換器 | 三菱（日本），西門子（德國） |
| 空氣開關 | 施奈德（法國） |
| 斷路器 | 西門子（德國） |
| 接觸 | 西門子（德國） |
| 光電開關 | 歐姆龍（日本） |
快速詳情
類型：灌裝機
成色：全新
應用：飲料，化學，醫療
包裝類型：瓶子
包裝材料：塑料
自動等級：自動
驅動類型：電動
電壓：380V / 220V
功率：4.8KW
產地：中國上海（大陸）
品牌名稱：VKPAK
尺寸（長*寬*高）：4250X2150X2200mm
重量：5200KGS
認證：CE，ISO，SGS
提供售後服務：工程師可在海外維修機械
工廠：LINKS MACHINERY
瓶子大小：150ml至2000ml
瓶頸直徑：15-55mm
瓶子材料：塑料/玻璃
速度（基於500毫升瓶裝）：15000B / H.
控制系統：PLC觸摸屏（MITSUBISHI JAPAN）
蓋：螺絲/壓蓋
蓋帽電梯：有
填充液體：礦物質/純淨水
